Ricoh Pro 8400 Series

monochrome with momentum.

Dedicated print and multifunction configurations for high-volume monochrome documents, manuals and book production.

view specifications
Ricoh Pro 8400 Series
Configuration shown may include optional equipment.
96–136pages/min · model dependent
350 g/m²maximum with suitable options
monoproduction printing
production workflowapplication-led configuration
overview

clear documents. a capable production platform.

Choose monochrome production for manuals, learning materials and customer communications. The shared series page keeps the Pro 8400S, 8410, 8410S, 8420 and 8420S specifications distinct, so speed and multifunction requirements can be compared properly.

specifications & options

Choose a model to compare its specifications and available options.

view specifications
back to cut-sheet printers
applications

make information easier to use.

Produce everyday reading material and data-driven documents with a consistent monochrome finish.

Stack of booklets; model-page finishing illustration.

manuals, course materials & books

Keep training packs and technical publications current with shorter print runs. Plan covers, dividers and binding around how the document will be handled and updated.

Illustration: black-and-white reports with grayscale charts on a natural wooden desk

forms & customer communications

Combine clear text, barcodes and variable information for suitable transactional workflows. Check the actual source file, any pre-printed stock and the finished output before approving a production run.

Application illustration; not a production sample.
monochrome quality

sharp text. considered detail.

Look beyond headline speed to the quality of the pages people read.

Magnified monochrome pixel pattern

imaging and registration

Ricoh's VCSEL imaging supports detailed monochrome output. Paper registration helps maintain image placement, particularly for duplex manuals and work on pre-printed sheets.

Curving black paper sheets

media that supports the document

Suitable optional feeding equipment supports stocks up to 350 g/m². Keep the paper profile and feed route matched to coated, uncoated or other approved media, and check the selected model's limits.

productivity

choose the pace your team needs.

Compare the five Australian models without losing the differences between print-only and multifunction configurations.

8400 series large-capacity feed drawers.

96, 111 or 136 ppm

The Pro 8400S is rated at 96 ppm. The Pro 8410 and 8410S are rated at 111 ppm, and the Pro 8420 and 8420S at 136 ppm. Model-specific tables show each configuration's paper handling and options.

Two colleagues reviewing a laptop

scanning where it belongs

Choose an S model when copying and scanning are needed alongside production printing. The Pro 8410 and 8420 are print-only models; scanning capability is not implied across the whole series.

Two office colleagues speaking

prepare for repeated work

Paper-library settings and planned input/output capacity can reduce repeated setup. Review how operators will load stock, collect output and handle urgent document requests between longer runs.

finishing

finish the document,
not just the pages.

Consider booklet making, folding and output collection as part of the initial configuration.

Illustration: monochrome printed booklet covers with coloured physical indexing tabs

booklets, reports & learning packs

Suitable folding, punching and booklet-finishing options help turn loose sheets into usable documents. Choose according to the page count, paper weight and finished format.

Application illustration; not a production sample.
Illustration: Mixed paper stocks organised on a production supply shelf.

leave room for the workflow

Allow space for loading, paper storage and collecting completed work, as well as the equipment itself. A sample job is a useful way to check the handoff from printing to distribution.

Application illustration; not a production sample.
specifications

the details that matter.

Select a model, then open the specification groups to compare speed, media handling and equipment options.

key specifications

Pro 8400S
96 ppm
Pro 8410 / 8410S
111 ppm
Pro 8420 / 8420S
136 ppm
Colour mode
Monochrome printing
Paper sizes
8400S: 330.2 × 487.7 mm; 8410/8410S/8420/8420S: up to 330.2 × 700 mm with suitable options
Media weight
Up to 350 g/m² with suitable options

full specifications

Pro 8400S

Configuration
Functions
Copy, print, scan
Colour
No
Printer controller - standard
GWNX
Printer controller - optional
Fiery EB-36 controller
Storage
640 GB (320 GB x 2)
Document server
Maximum stored documents 3,000 Maximum pages of all stored documents 1 5,000 Maximum storage period 1-180 days, 1-96 hours, or no limit
CPU
Intel ApolloLake E3940 1.6 GHz
Memory - standard
2 GB
Operation panel
10.1" Smart Operation Panel (G3)
Physical dimensions
Physical dimensions (WxDxH)—mainframe
1,141 x 900 x 1,397 mm
Physical dimensions (WxDxH)—other
540 x 730 x 1,000 mm—5,000-sheet LCIT RT5160 (A4) 865 x 730 x 1,000 mm—4,400-sheet LCIT RT5170 (A3) 1,054 x 730 x 1,000 mm—4,840-sheet Vacuum-Feed LCIT RT5150 690 x 561 x 210 mm—500-sheet Multi-Bypass Tray BY5020 760 x 730 x 980 mm—3,250-sheet Finisher SR5130 760 x 730 x 980 mm—3,250-sheet Booklet Finisher SR5140 1,113 x 730 x 1,490 mm—4,500-sheet Finisher SR5110 1,113 x 730 x 1,490 mm—3,500-sheet Booklet Finisher SR5120 1,115 x 591 x 555 mm—Trimmer Unit TR5050 330 x 730 x 1,350 mm—Cover Interposer CI5040 209 x 730 x 1,000 mm—Multi-Folding Unit FD5030 400 x 600 x 480 mm—Shift Sort Tray SH5000
Weight—mainframe
428 kg
Weight—other
106 kg—5,000-sheet LCIT RT5160 (A4) 185 kg—4,400-sheet LCIT RT5170 (A3) 230 kg—4,840-sheet Vacuum-Feed LCIT RT5150 20 kg—500-sheet Multi-Bypass Tray BY5020 40 kg—3,250-sheet Finisher SR5130 60 kg—3,250-sheet Finisher SR5140 135 kg—4,500-sheet Finisher SR5110 160 kg—3,500-sheet Booklet Finisher SR5120 75 kg—Trimmer Unit TR5050 50 kg—Cover Interposer CI5040 45 kg—Multi-Folding Unit FD5030 11 kg—Shift Sort Tray SH5000
Minimum space requirements
100 mm—left 47 mm—rear 100 mm—right 57 mm—front
Reliability
Max monthly volume
1,000,000 prints
Machine life
60,000,000 prints or 5 years, whichever comes first
Duty cycle
2,900,000 prints per month
Average monthly volume
95,000 prints
Average monthly statement
75,000–300,000 prints—recommended document volume
Supply yields
Supply yields
82,000 prints per toner bottle—two bottles can be installed 2,400,000 images per drum unit 860,000 prints per developer bag 1,200,000 sheets per waste toner bottle—selectable as supply or service part Note: Toner yield is measured with the A4 LEF/6% test chart, and will vary depending on the original document, image sizes and type, and the device operating conditions. 5,000 staples per Type X cartridge for finisher SR5110/5120—normal staple 5,000 staples per Type V cartridge for finisher SR5130/5140—normal staple 5,000 staples per Type U cartridge for finisher SR5120—saddle stitch staple 2,000 staples per Type W cartridge for finisher SR5140—saddle stitch staple 5 cartridges per Type X refill for finisher SR5110/5120—normal staple 3 cartridges per Type V refill for finisher SR5130/5140—normal staple 2 cartridges per Type T refill for finisher SR5120—saddle stitch staple 4 cartridges per Type W refill for finisher SR5140—saddle stitch staple
Media handling
Standard input capacity (sheets)
3,300 sheets (0.1mm)—2,200-sheet tandem tray + 550-sheet paper tray 2 + 550-sheet paper tray 3 3,000 sheets (0.11mm)—2,000-sheet tandem tray + 500-sheet paper tray 2 + 500-sheet paper tray 3
Maximum input capacity (sheets)
8,850
Maximum output capacity (sheets)
3,250
Paper input configuration - standard
2,200-sheet tandem paper input tray (2 x 1,100 sheets), 2 x 550-sheet paper input trays, 220-sheet SPDF, duplex unit
Paper input configuration - optional
LCIT RT5160 (A4), LCIT RT5170 (A3), Vacuum-Feed LCT RT5150, Multi-Bypass Tray BY5020, A3/11" x 17" Tray Unit TK5020 (internal)
Paper output configuration - optional
Shift Sort Tray SH5000, Finisher SR5130, Booklet Finisher SR5140, Punch Unit PU3110, Output Jogger Unit Type S11, Booklet Finisher SR5120, Finisher SR5110, Punch Unit PU5030, Trimmer Unit TR5050 for Booklet Finisher SR5120, Cover Interposer CI5040, Decurl Unit DU5070, Multi-Folding Unit FD5030
Supported media
Tray 1 Plain, Recycled/Coloured, Pre-Printed, Pre-punched, Bond paper, Card Stock, Back Copied Tray 2 Plain, Recycled/Coloured, Pre-Printed, Pre-punched, Bond paper, Card Stock, Back Copied, OHP, Transparency Tray 3 Plain, Recycled/Coloured, Pre-Printed, Pre-punched, Bond paper, Card Stock, Back Copied, Transparency Bypass tray Plain, Recycled/Coloured, Letterhead, Pre-Printed, Pre-punched, Bond paper, Card Stock, OHP, Tab Stock, Back Copied, Transparency, Envelope Note: Back Copied paper can be fed but quality is not guaranteed. LCIT RT5160 Plain, Recycled/Coloured, Letterhead, Pre-Printed, Pre-punched, Bond paper, Card Stock, OHP, Tab Stock, Back Copied, Transparency, Label Note: Back Copied paper can be fed but quality is not guaranteed. LCIT RT5170 Plain, Recycled/Coloured, Letterhead, Pre-Printed, Pre-punched, Bond paper, Card Stock, OHP, Tab Stock, Back Copied, Transparency, Label, Envelope, Gloss/Matte Note: Back Copied and Label paper can be fed but quality is not guaranteed. Vacuum-Feed LCIT RT5150 Plain, Recycled/Coloured, Letterhead, Pre-Printed, Pre-punched, Bond paper, Card Stock, OHP, Tab Stock, Back Copied, Transparency, Label, Envelope, Gloss/Matte, NCR Note: Back Copied and NCR paper (Weight 0) can be fed but quality is not guaranteed. Pre-punched paper feeding direction must be specified. Pre-punched holes must be set to the trailing side of the paper.
Maximum paper size
13" x 19.2"
Media weight (g/m2)
40–350
Limitless paper supply
Supported
Connectivity
Interfaces - standard
Mainframe 10Base-T/100Base-Tx/1000Base-T (Gigabit Ethernet) USB 2.0 Type A—2 ports at rear of device, 2 on operation panel (1 card reader) USB 2.0 Type B—1 port at rear of device SD card slot—1 port at rear of device for card option Fiery EB-36 controller 10Base-T/100Base-Tx/1000Base-T (Gigabit Ethernet) Display Port—2 USB 2.0 Type A—4 ports at rear of device USB 3.2—2 ports at rear of device USB 3.0—3 ports on Fiery Quick Touch panel
Network protocols - standard
GWNX controller TCP/IP (IPv4, IPv6) Fiery EB-36 controller TCP/IP (IPv4, IPv6)
Interfaces - optional
Mainframe IEEE 802.11 a/b/g/n/ac Interface Unit Type M52 Fiery EB-36 controller Not available
Copy features
Copy speed
96 cpm
First copy time
6.3 seconds or less
Copy resolution
2,400 x 4,800 dpi—printing 600 x 600 dpi—scanning
Original size
Maximum 297 x 432 mm 297 x 431.8 mm—SPDF
Quantity selection
1–9,999
Zoom range
25%–400%, in 1% steps
Image density adjustment
9 levels
Colour mode
Greyscale—256 levels
Book copy
Supported
Series copy
Book to simplex, duplex to simplex
Combine copy
2, 4, or 8 pages into 1 simplex sheet 1, 2, or 4 duplex pages into 1 simplex sheet 4, 8, or 16 pages into 1 duplex sheet 2, 4, or 8 duplex pages into 1 duplex sheet
Cover sheet
Front and back covers—copy or blank
Slip sheet
Supported
Chaptering
Up to 100 chapters
Stapling
Supported—with finisher
Punch
Supported—with finisher and punch unit
Electronic sorting
Without shift sort—supported Rotate sort—not supported Shift sort—supported—with finisher or shift sort tray
Margin/erase adjustment
Margin adjustment 0–30mm—in 1 mm steps Default—Front page: 5mm left, Back page:5 mm right Erase centre and border 2–99 mm in 1 mm steps Creep Supported (magazine) Scan position Supported
Image adjustment
Sharp/soft—7 levels Contrast—9 levels Background density adjustment—9 levels
Stamps
User stamp—5 stamps Date stamp—4 styles Page numbering—6 styles Preset stamp—8 stamps Bates stamping—6 styles Printing copy prevention pattern—supported
Job presets
Up to 10 presets
Job programs
Up to 50 jobs
Copy modes
Text, Photo, Text/Photo, Generation Copy, Pale
Auto tray change
Supported
Centring
Supported
Image creation
Repeated, Double copy, Positive/negative, Erase inside, Erase outside
Other copy features
Home UI customisation, My Operation Panel, Operation manual on operation panel, External USB keyboard, QWERTZ layout keyboard, AZERTY layout keyboard, Smart device-like operability, Tiltable operation panel, Interrupt copy, Import/Export of user preference settings, Centralised address book management, Job log data report printout, Subset stapling, Text and photo separation sensitivity adjustment—9 levels, Sample copy
Print features
Print speed black and white
96 ppm
Printing technology
40-beam Vertical-Cavity Surface-Emitting Laser (VCSEL)
Fusing
Oil-less belt-fusing method
Print resolution
2,400 x 4,800 dpi—maximum Note: Engine print resolution is 1,200 x 4,800 dpi.
Page description languages (PDLs)
Standard PCL, PostScript 3 and PDF emulation, JPEG, TIFF Optional Genuine Adobe PostScript 3 and PDF, Intelligent Printer Data Stream (IPDS), XPS
Printer driver resolution
PCL 5 300 x 300 dpi, 600 x 600 dpi—1-bit PCL 6 600 x 600 dpi, 1,200 x 1,200 dpi—1-bit PostScript 3 300 x 300 dpi, 600 x 600 dpi, 1,200 x 1,200 dpi—1-bit IPDS 300 x 300 dpi, 600 x 600 dpi—1-bit
Duplex printing
Standard
Envelope printing
Supported—Bypass Tray BY5020, LCIT RT5170, Vacuum-Feed LCIT RT5150
Maximum printable area
Simplex, edge-to-edge print mode 320 x 457.2 mm—mainframe tray 2 320 x 487.7 mm—with A3 LCIT and bypass tray options Note: Image quality in areas that interfere with the print margins is not guaranteed.
Fiery controller
EFI Fiery EB-36 print controller—optional System version Fiery FS600 Pro Configuration External Printer driver languages PostScript 3 (CPSI v3020 and APPE v6.0), PCL 6 Resolution 1,200 dpi, 600 dpi Fonts PCL—80 PostScript 3 — 138 Supported file formats PS, PDF, EPS, TIFF, PPML, PDF/VT, FF1 &FF2 JPEG, DOC, DOCX, XLS, XLSX, PUB, PPT, PPTX Variable data printing (VDP) PPML v3.0 Fiery FreeForm v1 and 2.1 PDF/VT-1 and PDF/VT-2
Other print features
Purge tray, Decurl unit—optional, Media Identification Unit—optional, Limitless toner supply—twin toner bottles, Double feed detection—mainframe (standard); document feeder (optional), Sample print, Locked print, Hold print, Scheduled print, Stored print, Store and Print, CLP simulation, PDF Direct print, Mail to print, Classification codes, Bonjour, Windows Active Directory support, DDNS, PCL resident font adoption, Tray parameter change from Web Image Monitor, WS printer, Media Direct Print (Print from USB), Automatic job promotion, Poster print, Job spool
Print margin
Lead edge 4.0 ± 0.5 mm Trail edge 4.0 ± 1.0 mm (Print) Front 2.0 ± 1.5 mm Rear 2.0 ± 1.5 mm
Scan features
Scan speed
140 ipm—simplex 280 ipm—duplex
Scan methods
Scan to USB/SD, Scan to email, Scan to folder (SMB, FTP) Scan to URL, Scan to PDF/A, Scan to digitally signed PDF, Scan to searchable PDF (embedded) Note: Maximum scan size for 1,200 dpi is A5.
Scan mode
Black and white Text, text/line art, text/photo, photo, greyscale Colour Text/photo, glossy photo, Automatic Colour Selection
Scan area
Main scan 297 mm Sub-scan 432 mm 431.8 mm—from SPDF
Image density adjustment
Supported—9 levels
Scan to email—other features
Scan to email size 128–102,400 KB—with restriction 700 MB—without restriction Maximum email addresses per send 2,000—from HDD 500—direct input 100—via LDAP Email addresses stored in HDD Maximum email addresses—2,000 Maximum registered group addresses—500 Search method—by name, email address Body message Manual—maximum 80 characters over 1 line User pre-registered—maximum 400 characters via soft key, 80 characters over 5 lines Preset message—This e-mail includes attached file sent from <device name> Input subject Manual and user pre-registered—maximum 128 characters via soft key Preset message—supported LDAP search Supported Input file name Supported Input of destination email address via soft key Supported Simultaneous transmission Maximum 500 destinations Attention To, Cc, Bcc Program registration Up to 25 programs Divide and send Divide by page or size; default divide by size Resend Yes—default/No, retry 3 times
Scan to folder
Protocols SMB, FTP Resolution 100 dpi, 150 dpi, 200 dpi (default), 300 dpi, 400 dpi, 600 dpi Search for client folders SMB—browsing directly to the designated folder Scan to folder file types Single-page TIFF, JPEG, PDF, PDF/A, high-compression PDF Multi-page TIFF, PDF, PDF/A, high-compression PDF
Scanner compression methods
Black and white JBIG2, MH, MMR, MR Colour JPEG
Scanned file naming
Supported—with reference number setting, for example, SCAN0001
Scan to file types
Single- and multi-page TIFF Single-page JPEG Single- and multi-page PDF Single-page high-compression PDF
Other scan features
SADF/batch mode, Mixed size mode, Reduce/enlarge scanning, Split scan from booklet, WS scanner, LDAP support (email), Preview before transmission, PDF encryption, Drop-out colour send, Distributed Scan Management
Supported operating environments
Other supported environments
Fiery system requirements Windows operating systems These Windows versions (with latest service packs) are supported for printer drivers and Fiery applications: Windows 10—64-bit Windows 11—64-bit Windows Server 2016—64-bit Windows Server 2019 Windows Server 2022 Note: Please visit the EFI website to confirm the latest supported OS. Macintosh operating systems These Mac OS versions are supported for printer drivers: Mac OS v10.15.11, 12, 13, 14 Note: Please visit the EFI website to confirm the latest supported OS. HDD—for printing and utilities except Command WorkStation Windows—16 GB of available hard drive space Mac OS X—7 GB of available hard drive space Memory (RAM)—for printing and utilities except Command WorkStation Windows—4 GB of RAM or more recommended Mac OS X—4 GB of RAM or more recommended Networking protocols Windows—TCP/IP Mac OS X—TCP/IP, Bonjour Command WorkStation A monitor that supports 16-bit colour at a minimum resolution of 1,024 x 768 pixels TCP/IP networking protocol installed Windows 1.0 GHz or greater Pentium 4 processor 1 GB RAM or more Mac OS Intel processor that supports the version of Mac OS installed 4 GB RAM or more SeeQuence (Impose and Compose) on Command WorkStation In addition to requirements for Command WorkStation: Licence activation for every client workstation Acrobat/PitStop software
Software and solutions
Standard
Device management and monitoring @Remote Web Image Monitor Device Manager NX Lite Workflow solutions Streamline NX TotalFlow Production Manager TotalFlow Prep RICOH InfoPrint Manager BatchBuilder RICOH Process Director RICOH Supervisor FusionPro VDP Creator
Environmental features
Power source
220–240 V, 50/60 Hz, 13 Amps—mainframe 100–240 V, 50/60 Hz, 1–1.5 Amps—Fiery controller
Power consumption
2,860 W—maximum 0.94 W—Energy Saver Mode (Sleep Mode)
Power consumption—options
224 W—5,000-sheet LCIT RT5160 (A4) 324 W or less—4,400-sheet LCIT RT5170 (A3) 1,000 W—4,840-sheet Vacuum-Feed LCIT RT5150 67 W—3,250-sheet Finisher SR5130 67 W—3,250-sheet Booklet Finisher SR5140 15 W—Output Jogger Unit Type S11 150 W—4,500-sheet Finisher SR5110 150 W—3,500-sheet Booklet Finisher SR5120 250 W maximum, 75 W average—Trimmer Unit TR5050 20 W—Shift Sort Tray SH5000 110 W excluding peak consumption—Cover Interposer CI5040 30 W or less—Decurl Unit DU5070 60 W or less—Multi-Folding Unit FD5030 80 W—Fiery EB-36 controller
Warm-up time
300 seconds or less—at temperature of 23&deg;C
Sound power level
Mainframe 60.4 dB or less—standby 71 dB or less—printing Full system 72.6 dB or less—printing
Emission levels
0.02 mg/h or less—benzene 1.5 mg/h or less—dust 0.48 mg/h or less—ozone 0.10 mg/h or less—styrene
Safety standards
EN62368-1 IEC60950-1
Electromagnetic Compatibility (EMC) standards
EN62311 EN55032 EN55035 EN61000-3-2, EN61000-3-3 AS/NZS CISPR32
Wireless LAN standards
EN301489-1 EN301489-3 EN301489-17 AS/NZS 4268
Typical Electricity Consumption (TEC)
11.9 kWh
Total Volatile Organic Compounds (TVOC)
4.18 mg/h—printing 0.0092 mg/h—standby

Pro 8410

Configuration
Functions
Print
Colour
No
Printer controller - standard
GWNX
Printer controller - optional
Fiery EB-36 controller
Storage
640 GB (320 GB x 2)
Document server
Maximum stored documents 3,000 Maximum pages of all stored documents 15,000 Maximum storage period 1-180 days, 1-96 hours, or no limit
CPU
Intel ApolloLake E3940 1.6 GHz
Memory - standard
2 GB
Operation panel
10.1” Smart Operation Panel (G3)
Physical dimensions
Physical dimensions (WxDxH)—mainframe
1,141 x 900 x 1,750 mm
Physical dimensions (WxDxH)—other
540 x 730 x 1,000 mm—5,000-sheet LCIT RT5160 (A4) 865 x 730 x 1,000 mm—4,400-sheet LCIT RT5170 (A3) 1,054 x 730 x 1,000 mm—4,840-sheet Vacuum-Feed LCIT RT5150 690 x 561 x 210 mm—500-sheet Multi-Bypass Tray BY5020 1,090 x 561 x 210 mm—Multi-Bypass Banner Tray Type S9, when attached to Multi-Bypass Tray BY5020 330 x 730 x 1,000 mm—Bridge Unit BU5010 1,113 x 730 x 1,490 mm—4,500-sheet Finisher SR5110 1,113 x 730 x 1,490 mm—3,500-sheet Booklet Finisher SR5120 1,115 x 591 x 555 mm—Trimmer Unit TR5050 330 x 730 x 1,350 mm—Cover Interposer CI5040 900 x 730 x 1,010 mm—High-Capacity Stacker SK5040 470 x 730 x 1,000 mm—Multi-Folding Unit FD5020 209 x 730 x 1,000 mm—Multi-Folding Unit FD5030 330 x 740 x 1,010 mm—Bridge Unit BU5020 330 x 730 x 1,010 mm—Buffer Pass Unit Type S11 265 x 253 x 136 mm—RPIP Interface Box Type S3
Weight—mainframe
413 kg
Weight—other
106 kg—5,000-sheet LCIT RT5160 (A4) 185 kg—4,400-sheet LCIT RT5170 (A3) 230 kg—4,840-sheet Vacuum-Feed LCIT RT5150 20 kg—500-sheet Multi-Bypass Tray BY5020 3.5 kg—500-sheet Multi-Bypass Banner Tray Type S9 40 kg—Bridge Unit BU5010 135 kg—4,500-sheet Finisher SR5110 160 kg—3,500-sheet Booklet Finisher SR5120 75 kg—Trimmer Unit TR5050 50 kg—Cover Interposer CI5040 131 kg—High-Capacity Stacker SK5040 15 kg—Roll-Away Cart 92 kg—Multi-Folding Unit FD5020 45 kg—Multi-Folding Unit FD5030 40 kg—Bridge Unit BU5020 90 kg—Buffer Pass Unit Type S11
Minimum space requirements
100 mm—left 47 mm—rear 100 mm—right 57 mm—front
Reliability
Max monthly volume
1,000,000 prints
Machine life
60,000,000 prints or 5 years, whichever comes first
Duty cycle
3,300,000 prints per month
Average monthly volume
200,000 prints
Average monthly statement
250,000–600,000 prints—recommended document volume
Supply yields
Supply yields
82,000 prints per toner bottle—two bottles can be installed 2,400,000 images per drum unit 860,000 prints per developer bag 1,200,000 sheets per waste toner bottle—selectable as supply or service part Note: Toner yield is measured with the A4 LEF/6% test chart, and will vary depending on the original document, image sizes and type, and the device operating conditions. 5,000 staples per Type X cartridge for finisher SR5110/5120—normal staple 5,000 staples per Type U cartridge for finisher SR5120—saddle stitch staple 5 cartridges per Type X refill for finisher SR5110/5120—normal staple 2 cartridges per Type T refill for finisher SR5120—saddle stitch staple
Media handling
Standard input capacity (sheets)
3,300 sheets (0.1mm)—2,200-sheet tandem tray + 550-sheet paper tray 2 + 550-sheet paper tray 3 3,000 sheets (0.11mm)—2,000-sheet tandem tray + 500-sheet paper tray 2 + 500-sheet paper tray 3
Maximum input capacity (sheets)
16,700
Maximum output capacity (sheets)
15,000
Paper input configuration - standard
2,200-sheet tandem paper input tray (2 x 1,100 sheets), 2 x 550-sheet paper input trays, duplex unit
Paper input configuration - optional
LCIT RT5160 (A4), LCIT RT5170 (A3), Vacuum-Feed LCIT RT5150, Multi-Bypass Tray BY5020, Multi-Bypass Banner Sheet Tray Type S9, Vacuum-Feed Banner Sheet Tray Type S9, Bridge Unit BU5010, A3/11" x 17" Tray Unit TK5020 (internal)
Paper output configuration - optional
Booklet Finisher SR5120, Finisher SR5110, Punch Unit PU5030, Trimmer Unit TR5050 for Booklet Finisher SR5120, Cover Interposer CI5040, SR5000 Series Output Tray For Banner Sheet Type S6, Decurl Unit DU5070, High-Capacity Stacker SK5040, Multi-Folding Unit FD5020, Multi-Folding Unit FD5030, Bridge Unit BU5020 (for third party finishers)
Paper output configuration - 3rd Party
Plockmatic PBM 350e, Plockmatic Rotate Crease Trim (RCT) e, Plockmatic SBT (Square Back Trimmer), Plockmatic CT XL, Plockmatic HCI3500 High-Capacity Interposer, GBC StreamPunch Plus 220V RICOH, GBC StreamWire
Supported media
Tray 1 Plain, Recycled/Coloured, Pre-Printed, Pre-punched, Bond paper, Card Stock, Back Copied Tray 2 Plain, Recycled/Coloured, Pre-Printed, Pre-punched, Bond paper, Card Stock, Back Copied, OHP, Transparency Tray 3 Plain, Recycled/Coloured, Pre-Printed, Pre-punched, Bond paper, Card Stock, Back Copied, Transparency Bypass tray, Bypass banner sheet tray Plain, Recycled/Coloured, Letterhead, Pre-Printed, Pre-punched, Bond paper, Card Stock, OHP, Tab Stock, Back Copied, Transparency, Envelope Note: Back Copied paper can be fed but quality is not guaranteed. LCIT RT5160 Plain, Recycled/Coloured, Letterhead, Pre-Printed, Pre-punched, Bond paper, Card Stock, OHP, Tab Stock, Back Copied, Transparency, Label Note: Back Copied paper can be fed but quality is not guaranteed. LCIT RT5170 Plain, Recycled/Coloured, Letterhead, Pre-Printed, Pre-punched, Bond paper, Card Stock, OHP, Tab Stock, Back Copied, Transparency, Label, Envelope, Gloss/Matte Note: Back Copied and Label paper can be fed but quality is not guaranteed. Vacuum-Feed LCIT RT5150 Plain, Recycled/Coloured, Letterhead, Pre-Printed, Pre-punched, Bond paper, Card Stock, OHP, Tab Stock, Back Copied, Transparency, Label, Envelope, Gloss/Matte, NCR Note: Back Copied and NCR paper (Weight 0) can be fed but quality is not guaranteed. Pre-punched paper feeding direction must be specified. Pre-punched holes must be set to the trailing side of the paper.
Maximum paper size
330.2 x 700 mm
Media weight (g/m2)
40–350
Limitless paper supply
Supported
Connectivity
Interfaces - standard
Mainframe 10Base-T/100Base-Tx/1000Base-T (Gigabit Ethernet) USB 2.0 Type A—2 ports at rear of device, 2 on operation panel (1 card reader) USB 2.0 Type B—1 port at rear of device SD card slot—1 port at rear of device for card option Fiery EB-36 controller 10Base-T/100Base-Tx/1000Base-T (Gigabit Ethernet) Display Port—2 USB 2.0 Type A—4 ports at rear of device USB 3.2—2 ports at rear of device USB 3.0—3 ports on Fiery Quick Touch panel
Network protocols - standard
GWNX controller TCP/IP (IPv4, IPv6) Fiery EB-36 controller TCP/IP (IPv4, IPv6)
Interfaces - optional
Mainframe IEEE 802.11 a/b/g/n/ac Interface Unit Type M52 Fiery EB-36 controller Not available
Print features
Print speed black and white
111 ppm
Printing technology
40-beam Vertical-Cavity Surface-Emitting Laser (VCSEL)
Fusing
Oil-less belt-fusing method
Print resolution
2,400 x 4,800 dpi—maximum Note: Engine print resolution is 1,200 x 4,800 dpi.
Page description languages (PDLs)
Standard PCL, PostScript 3 and PDF emulation, JPEG, TIFF Optional Genuine Adobe PostScript 3 and PDF, Intelligent Printer Data Stream (IPDS), XPS
Printer driver resolution
PCL 5 300 x 300 dpi, 600 x 600 dpi—1-bit PCL 6 600 x 600 dpi, 1,200 x 1,200 dpi—1-bit PostScript 3 300 x 300 dpi, 600 x 600 dpi, 1,200 x 1,200 dpi—1-bit IPDS 300 x 300 dpi, 600 x 600 dpi—1-bit
Duplex printing
Standard
Envelope printing
Supported—Bypass Tray BY5020, LCIT RT5170, Vacuum-Feed LCIT RT5150
Maximum printable area
Simplex, edge-to-edge print mode 320 x 457.2 mm—mainframe tray 2 320 x 487.7 mm—with A3 LCIT and bypass tray options Note: Image quality in areas that interfere with the print margins is not guaranteed.
Fiery controller
EFI Fiery EB-36 print controller—optional System version Fiery FS600 Pro Configuration External Printer driver languages PostScript 3 (CPSI v3020 and APPE v6.0), PCL 6 Resolution 1,200 dpi, 600 dpi Fonts PCL—80 PostScript 3 — 138 Supported file formats PS, PDF, EPS, TIFF, PPML, PDF/VT, FF1 &FF2 JPEG, DOC, DOCX, XLS, XLSX, PUB, PPT, PPTX Variable data printing (VDP) PPML v3.0 Fiery FreeForm v1 and 2.1 PDF/VT-1 and PDF/VT-2
Other print features
Purge tray, Decurl unit—optional, Media Identification Unit—optional, Limitless toner supply—twin toner bottles, Double feed detection, Sample print, Locked print, Hold print, Scheduled print, Stored print, Store and Print, CLP simulation, PDF Direct print, Mail to print, Classification codes, Bonjour, Windows Active Directory support, DDNS, PCL resident font adoption, Tray parameter change from Web Image Monitor, WS printer, Media Direct Print (Print from USB), Automatic job promotion, Poster print, Job spool
Print margin
Lead edge 4.0 &plusmn; 0.5 mm Trail edge 4.0 &plusmn; 1.0 mm (Print) Front 2.0 &plusmn; 1.5 mm Rear 2.0 &plusmn; 1.5 mm
Supported operating environments
Other supported environments
Fiery system requirements Windows operating systems These Windows versions (with latest service packs) are supported for printer drivers and Fiery applications: Windows 10—64-bit Windows 11—64-bit Windows Server 2016—64-bit Windows Server 2019 Windows Server 2022 Note: Please visit the EFI website to confirm the latest supported OS. Macintosh operating systems These Mac OS versions are supported for printer drivers: Mac OS v10.15.11, 12, 13, 14 Note: Please visit the EFI website to confirm the latest supported OS. HDD—for printing and utilities except Command WorkStation Windows—16 GB of available hard drive space Mac OS X—7 GB of available hard drive space Memory (RAM)—for printing and utilities except Command WorkStation Windows—4 GB of RAM or more recommended Mac OS X—4 GB of RAM or more recommended Networking protocols Windows—TCP/IP Mac OS X—TCP/IP, Bonjour Command WorkStation A monitor that supports 16-bit colour at a minimum resolution of 1,024 x 768 pixels TCP/IP networking protocol installed Windows 1.0 GHz or greater Pentium 4 processor 1 GB RAM or more Mac OS Intel processor that supports the version of Mac OS installed 4 GB RAM or more SeeQuence (Impose and Compose) on Command WorkStation In addition to requirements for Command WorkStation: Licence activation for every client workstation Acrobat/PitStop software
Software and solutions
Standard
Device management and monitoring @Remote Web Image Monitor Device Manager NX Lite Workflow solutions Streamline NX TotalFlow Production Manager TotalFlow Prep RICOH InfoPrint Manager BatchBuilder RICOH Process Director RICOH Supervisor FusionPro VDP Creator
Environmental features
Power source
220–240 V, 50/60 Hz, 15 Amps—mainframe 100–240 V, 50/60 Hz, 1–1.5 Amps—Fiery controller
Power consumption
3,300 W—maximum 0.94 W—Energy Saver Mode (Sleep Mode)
Power consumption—options
224 W—5,000-sheet LCIT RT5160 (A4) 324 W or less—4,400-sheet LCIT RT5170 (A3) 1,000 W—4,840-sheet Vacuum-Feed LCIT RT5150 150 W—4,500-sheet Finisher SR5110 150 W—3,500-sheet Booklet Finisher SR5120 250 W maximum, 75 W average—Trimmer Unit TR5050 95 W excluding peak consumption—Cover Interposer CI5040 30 W or less—Decurl Unit DU5070 144 W—High-Capacity Stacker SK5040 240 W—Multi-Folding Unit FD5020 60 W or less—Multi-Folding Unit FD5030 200 W or less—Buffer Pass Unit Type S11 8 W or less—Bridge Unit BU5020 80 W—Fiery EB-36 controller
Warm-up time
300 seconds or less—at temperature of 23&deg;C
Sound power level
Mainframe 60.4 dB or less—standy 72 dB or less—printing Full system 78.1 dB or less—printing
Emission levels
0.02 mg/h or less—benzene 1.5 mg/h or less—dust 0.48 mg/h or less—ozone 0.10 mg/h or less—styrene
Safety standards
EN62368-1 IEC60950-1
Electromagnetic Compatibility (EMC) standards
EN62311 EN55032 EN55035 EN61000-3-2, EN61000-3-3 AS/NZS CISPR32
Wireless LAN standards
EN301489-1 EN301489-3 EN301489-17 AS/NZS 4268
Typical Electricity Consumption (TEC)
13.7 kWh
Total Volatile Organic Compounds (TVOC)
4.18 mg/h—printing 0.0092 mg/h—standby

Pro 8410S

Configuration
Functions
Copy, print, scan
Colour
No
Printer controller - standard
GWNX
Printer controller - optional
Fiery EB-36 controller
Storage
640 GB (320 GB x 2)
Document server
Maximum stored documents 3,000 Maximum pages of all stored documents 15,000 Maximum storage period 1-180 days, 1-96 hours, or no limit
CPU
Intel ApolloLake E3940 1.6 GHz
Memory - standard
2 GB
Operation panel
10.1" Smart Operation Panel (G3)
Physical dimensions
Physical dimensions (WxDxH)—mainframe
1,141 x 900 x 1,750 mm
Physical dimensions (WxDxH)—other
540 x 730 x 1,000 mm—5,000-sheet LCIT RT5160 (A4) 865 x 730 x 1,000 mm—4,400-sheet LCIT RT5170 (A3) 1,054 x 730 x 1,000 mm—4,840-sheet Vacuum-Feed LCIT RT5150 690 x 561 x 210 mm—500-sheet Multi-Bypass Tray BY5020 1,090 x 561 x 210 mm—Multi-Bypass Banner Tray Type S9, when attached to Multi-Bypass Tray BY5020 330 x 730 x 1,000 mm—Bridge Unit BU5010 1,113 x 730 x 1,490 mm—4,500-sheet Finisher SR5110 1,113 x 730 x 1,490 mm—3,500-sheet Booklet Finisher SR5120 1,115 x 591 x 555 mm—Trimmer Unit TR5050 330 x 730 x 1,350 mm—Cover Interposer CI5040 900 x 730 x 1,010 mm—High-Capacity Stacker SK5040 470 x 730 x 1,000 mm—Multi-Folding Unit FD5020 209 x 730 x 1,000 mm—Multi-Folding Unit FD5030 330 x 740 x 1,010 mm—Bridge Unit BU5020 330 x 730 x 1,010 mm—Buffer Pass Unit Type S11 265 x 253 x 136 mm—RPIP Interface Box Type S3
Weight—mainframe
428 kg
Weight—other
106 kg—5,000-sheet LCIT RT5160 (A4) 185 kg—4,400-sheet LCIT RT5170 (A3) 230 kg—4,840-sheet Vacuum-Feed LCIT RT5150 20 kg—500-sheet Multi-Bypass Tray BY5020 3.5 kg—500-sheet Multi-Bypass Banner Tray Type S9 40 kg—Bridge Unit BU5010 135 kg—4,500-sheet Finisher SR5110 160 kg—3,500-sheet Booklet Finisher SR5120 75 kg—Trimmer Unit TR5050 50 kg—Cover Interposer CI5040 131 kg—High-Capacity Stacker SK5040 15 kg—Roll-Away Cart 92 kg—Multi-Folding Unit FD5020 45 kg—Multi-Folding Unit FD5030 40 kg—Bridge Unit BU5020 90 kg—Buffer Pass Unit Type S11
Minimum space requirements
100 mm—left 47 mm—rear 100 mm—right 57 mm—front
Reliability
Max monthly volume
1,000,000 prints
Machine life
60,000,000 prints or 5 years, whichever comes first
Duty cycle
3,300,000 prints per month
Average monthly volume
150,000 prints
Average monthly statement
150,000–500,000 prints—recommended document volume
Supply yields
Supply yields
82,000 prints per toner bottle—two bottles can be installed 2,400,000 images per drum unit 860,000 prints per developer bag 1,200,000 sheets per waste toner bottle—selectable as supply or service part Note: Toner yield is measured with the A4 LEF/6% test chart, and will vary depending on the original document, image sizes and type, and the device operating conditions. 5,000 staples per Type X cartridge for finisher SR5110/5120—normal staple 5,000 staples per Type U cartridge for finisher SR5120—saddle stitch staple 5 cartridges per Type X refill for finisher SR5110/5120—normal staple 2 cartridges per Type T refill for finisher SR5120—saddle stitch staple
Media handling
Standard input capacity (sheets)
3,300 sheets (0.1mm)—2,200-sheet tandem tray + 550-sheet paper tray 2 + 550-sheet paper tray 3 3,000 sheets (0.11mm)—2,000-sheet tandem tray + 500-sheet paper tray 2 + 500-sheet paper tray 3
Maximum input capacity (sheets)
16,700
Maximum output capacity (sheets)
15,000
Paper input configuration - standard
2,200-sheet tandem paper input tray (2 x 1,100 sheets), 2 x 550-sheet paper input trays, 220-sheet SPDF, duplex unit
Paper input configuration - optional
LCIT RT5160 (A4), LCIT RT5170 (A3), Vacuum-Feed LCIT RT5150, Multi-Bypass Tray BY5020, Multi-Bypass Banner Sheet Tray Type S9, Vacuum-Feed Banner Sheet Tray Type S9, Bridge Unit BU5010, A3/11" x 17" Tray Unit TK5020 (internal)
Paper output configuration - optional
Booklet Finisher SR5120, Finisher SR5110, Punch Unit PU5030, Trimmer Unit TR5050 for Booklet Finisher SR5120, Cover Interposer CI5040, SR5000 Series Output Tray For Banner Sheet Type S6, Decurl Unit DU5070, High-Capacity Stacker SK5040, Multi-Folding Unit FD5020, Multi-Folding Unit FD5030, Bridge Unit BU5020 (for third party finishers)
Paper output configuration - 3rd Party
Plockmatic PBM 350e, Plockmatic Rotate Crease Trim (RCT) e, Plockmatic SBT (Square Back Trimmer), Plockmatic CT XL, Plockmatic HCI3500 High-Capacity Interposer,GBC StreamPunch Plus 220V RICOH, GBC StreamWire
Supported media
Tray 1 Plain, Recycled/Coloured, Pre-Printed, Pre-punched, Bond paper, Card Stock, Back Copied Tray 2 Plain, Recycled/Coloured, Pre-Printed, Pre-punched, Bond paper, Card Stock, Back Copied, OHP, Transparency Tray 3 Plain, Recycled/Coloured, Pre-Printed, Pre-punched, Bond paper, Card Stock, Back Copied, Transparency Bypass tray, Bypass banner sheet tray Plain, Recycled/Coloured, Letterhead, Pre-Printed, Pre-punched, Bond paper, Card Stock, OHP, Tab Stock, Back Copied, Transparency, Envelope Note: Back Copied paper can be fed but quality is not guaranteed. LCIT RT5160 Plain, Recycled/Coloured, Letterhead, Pre-Printed, Pre-punched, Bond paper, Card Stock, OHP, Tab Stock, Back Copied, Transparency, Label Note: Back Copied paper can be fed but quality is not guaranteed. LCIT RT5170 Plain, Recycled/Coloured, Letterhead, Pre-Printed, Pre-punched, Bond paper, Card Stock, OHP, Tab Stock, Back Copied, Transparency, Label, Envelope, Gloss/Matte Note: Back Copied and Label paper can be fed but quality is not guaranteed. Vacuum-Feed LCIT RT5150 Plain, Recycled/Coloured, Letterhead, Pre-Printed, Pre-punched, Bond paper, Card Stock, OHP, Tab Stock, Back Copied, Transparency, Label, Envelope, Gloss/Matte, NCR Note: Back Copied and NCR paper (Weight 0) can be fed but quality is not guaranteed. Pre-punched paper feeding direction must be specified. Pre-punched holes must be set to the trailing side of the paper.
Maximum paper size
330.2 x 700 mm
Media weight (g/m2)
40–350
Limitless paper supply
Supported
Connectivity
Interfaces - standard
Mainframe 10Base-T/100Base-Tx/1000Base-T (Gigabit Ethernet) USB 2.0 Type A—2 ports at rear of device, 2 on operation panel (1 card reader) USB 2.0 Type B—1 port at rear of device SD card slot—1 port at rear of device for card option Fiery EB-36 controller 10Base-T/100Base-Tx/1000Base-T (Gigabit Ethernet) Display Port—2 USB 2.0 Type A—4 ports at rear of device USB 3.2—2 ports at rear of device USB 3.0—3 ports on Fiery Quick Touch panel
Network protocols - standard
GWNX controller TCP/IP (IPv4, IPv6) Fiery EB-36 controller TCP/IP (IPv4, IPv6)
Interfaces - optional
Mainframe IEEE 802.11 a/b/g/n/ac Interface Unit Type M52 Fiery EB-36 controller Not available
Copy features
Copy speed
111 cpm
First copy time
5.6 seconds or less
Copy resolution
2,400 x 4,800 dpi—printing 600 x 600 dpi—scanning
Original size
Maximum 297 x 432 mm 297 x 431.8 mm—SPDF
Quantity selection
1–9,999
Zoom range
25%–400%, in 1% steps
Image density adjustment
9 levels
Colour mode
Greyscale—256 levels
Book copy
Supported
Series copy
Book to simplex, duplex to simplex
Combine copy
2, 4, or 8 pages into 1 simplex sheet 1, 2, or 4 duplex pages into 1 simplex sheet 4, 8, or 16 pages into 1 duplex sheet 2, 4, or 8 duplex pages into 1 duplex sheet
Cover sheet
Front and back covers—copy or blank
Slip sheet
Supported
Chaptering
Up to 100 chapters
Stapling
Supported—with finisher
Punch
Supported—with finisher and punch unit
Electronic sorting
Without shift sort—supported Rotate sort—not supported Shift sort—supported—with finisher or shift sort tray
Margin/erase adjustment
Margin adjustment 0–30mm—in 1 mm steps Default—Front page: 5mm left, Back page:5 mm right Erase centre and border 2–99 mm in 1 mm steps Creep Supported (magazine) Scan position Supported
Image adjustment
Sharp/soft—7 levels Contrast—9 levels Background density adjustment—9 levels
Stamps
User stamp—5 stamps Date stamp—4 styles Page numbering—6 styles Preset stamp—8 stamps Bates stamping—6 styles Printing copy prevention pattern—supported
Job presets
Up to 10 presets
Job programs
Up to 50 jobs
Copy modes
Text, Photo, Text/Photo, Generation Copy, Pale
Auto tray change
Supported
Centring
Supported
Image creation
Repeated, Double copy, Positive/negative, Erase inside, Erase outside
Other copy features
Home UI customisation, My Operation Panel, Operation manual on operation panel, External USB keyboard, QWERTZ layout keyboard, AZERTY layout keyboard, Smart device-like operability, Tiltable operation panel, Interrupt copy, Import/Export of user preference settings, Centralised address book management, Job log data report printout, Subset stapling, Text and photo separation sensitivity adjustment—9 levels, Sample copy
Print features
Print speed black and white
111 ppm
Printing technology
40-beam Vertical-Cavity Surface-Emitting Laser (VCSEL)
Fusing
Oil-less belt-fusing method
Print resolution
2,400 x 4,800 dpi—maximum Note: Engine print resolution is 1,200 x 4,800 dpi.
Page description languages (PDLs)
Standard PCL, PostScript 3 and PDF emulation, JPEG, TIFF Optional Genuine Adobe PostScript 3 and PDF, Intelligent Printer Data Stream (IPDS), XPS
Printer driver resolution
PCL 5 300 x 300 dpi, 600 x 600 dpi—1-bit PCL 6 600 x 600 dpi, 1,200 x 1,200 dpi—1-bit PostScript 3 300 x 300 dpi, 600 x 600 dpi, 1,200 x 1,200 dpi—1-bit IPDS 300 x 300 dpi, 600 x 600 dpi—1-bit
Duplex printing
Standard
Envelope printing
Supported—Bypass Tray BY5020, LCIT RT5170, Vacuum-Feed LCIT RT5150
Maximum printable area
Simplex, edge-to-edge print mode 320 x 457.2 mm—mainframe tray 2 320 x 487.7 mm—with A3 LCIT and bypass tray options Note: Image quality in areas that interfere with the print margins is not guaranteed.
Fiery controller
EFI Fiery EB-36 print controller—optional System version Fiery FS600 Pro Configuration External Printer driver languages PostScript 3 (CPSI v3020 and APPE v6.0), PCL 6 Resolution 1,200 dpi, 600 dpi Fonts PCL—80 PostScript 3 — 138 Supported file formats PS, PDF, EPS, TIFF, PPML, PDF/VT, FF1 &FF2 JPEG, DOC, DOCX, XLS, XLSX, PUB, PPT, PPTX Variable data printing (VDP) PPML v3.0 Fiery FreeForm v1 and 2.1 PDF/VT-1 and PDF/VT-2
Other print features
Purge tray, Decurl unit—optional, Media Identification Unit—optional, Limitless toner supply—twin toner bottles, Double feed detection—mainframe (standard); document feeder (optional), Sample print, Locked print, Hold print, Scheduled print, Stored print, Store and Print, CLP simulation, PDF Direct print, Mail to print, Classification codes, Bonjour, Windows Active Directory support, DDNS, PCL resident font adoption, Tray parameter change from Web Image Monitor, WS printer, Media Direct Print (Print from USB), Automatic job promotion, Poster print, Job spool
Print margin
Lead edge 4.0 &plusmn; 0.5 mm Trail edge 4.0 &plusmn; 1.0 mm (Print) Front 2.0 &plusmn; 1.5 mm Rear 2.0 &plusmn; 1.5 mm
Scan features
Scan speed
140 ipm—simplex 280 ipm—duplex
Scan methods
Scan to USB/SD, Scan to email, Scan to folder (SMB, FTP) Scan to URL, Scan to PDF/A, Scan to digitally signed PDF, Scan to searchable PDF (embedded) Note: Maximum scan size for 1,200 dpi is A5.
Scan mode
Black and white Text, text/line art, text/photo, photo, greyscale Colour Text/photo, glossy photo, Automatic Colour Selection
Scan area
Main scan 297 mm Sub-scan 432 mm 431.8 mm—from SPDF
Image density adjustment
Supported—9 levels
Scan to email—other features
Scan to email size 128–102,400 KB—with restriction 700 MB—without restriction Maximum email addresses per send 2,000—from HDD 500—direct input 100—via LDAP Email addresses stored in HDD Maximum email addresses—2,000 Maximum registered group addresses—500 Search method—by name, email address Body message Manual—maximum 80 characters over 1 line User pre-registered—maximum 400 characters via soft key, 80 characters over 5 lines Preset message—This e-mail includes attached file sent from <device name> Input subject Manual and user pre-registered—maximum 128 characters via soft key Preset message—supported LDAP search Supported Input file name Supported Input of destination email address via soft key Supported Simultaneous transmission Maximum 500 destinations Attention To, Cc, Bcc Program registration Up to 25 programs Divide and send Divide by page or size; default divide by size Resend Yes—default/No, retry 3 times
Scan to folder
Protocols SMB, FTP Resolution 100 dpi, 150 dpi, 200 dpi (default), 300 dpi, 400 dpi, 600 dpi Search for client folders SMB—browsing directly to the designated folder Scan to folder file types Single-page TIFF, JPEG, PDF, PDF/A, high-compression PDF Multi-page TIFF, PDF, PDF/A, high-compression PDF
Scanner compression methods
Black and white JBIG2, MH, MMR, MR Colour JPEG
Scanned file naming
Supported—with reference number setting, for example, SCAN0001
Scan to file types
Single- and multi-page TIFF Single-page JPEG Single- and multi-page PDF Single-page high-compression PDF
Other scan features
SADF/batch mode, Mixed size mode, Reduce/enlarge scanning, Split scan from booklet, WS scanner, LDAP support (email), Preview before transmission, PDF encryption, Drop-out colour send, Distributed Scan Management
Supported operating environments
Other supported environments
Fiery system requirements Windows operating systems These Windows versions (with latest service packs) are supported for printer drivers and Fiery applications: Windows 10—64-bit Windows 11—64-bit Windows Server 2016—64-bit Windows Server 2019 Windows Server 2022 Note: Please visit the EFI website to confirm the latest supported OS. Macintosh operating systems These Mac OS versions are supported for printer drivers: Mac OS v10.15.11, 12, 13, 14 Note: Please visit the EFI website to confirm the latest supported OS. HDD—for printing and utilities except Command WorkStation Windows—16 GB of available hard drive space Mac OS X—7 GB of available hard drive space Memory (RAM)—for printing and utilities except Command WorkStation Windows—4 GB of RAM or more recommended Mac OS X—4 GB of RAM or more recommended Networking protocols Windows—TCP/IP Mac OS X—TCP/IP, Bonjour Command WorkStation A monitor that supports 16-bit colour at a minimum resolution of 1,024 x 768 pixels TCP/IP networking protocol installed Windows 1.0 GHz or greater Pentium 4 processor 1 GB RAM or more Mac OS Intel processor that supports the version of Mac OS installed 4 GB RAM or more SeeQuence (Impose and Compose) on Command WorkStation In addition to requirements for Command WorkStation: Licence activation for every client workstation Acrobat/PitStop software
Software and solutions
Standard
Device management and monitoring @Remote Web Image Monitor Device Manager NX Lite Workflow solutions Streamline NX TotalFlow Production Manager TotalFlow Prep RICOH InfoPrint Manager BatchBuilder RICOH Process Director RICOH Supervisor FusionPro VDP Creator
Environmental features
Power source
220–240 V, 50/60 Hz, 15 Amps—mainframe 100–240 V, 50/60 Hz, 1–1.5 Amps—Fiery controller
Power consumption
3,300 W—maximum 0.94 W—Energy Saver Mode (Sleep Mode)
Power consumption—options
224 W—5,000-sheet LCIT RT5160 (A4) 324 W or less—4,400-sheet LCIT RT5170 (A3) 1,000 W—4,840-sheet Vacuum-Feed LCIT RT5150 67 W—3,250-sheet Finisher SR5130 67 W—3,250-sheet Booklet Finisher SR5140 15 W—Output Jogger Unit Type S11 150 W—4,500-sheet Finisher SR5110 150 W—3,500-sheet Booklet Finisher SR5120 250 W maximum, 75 W average—Trimmer Unit TR5050 20 W—Shift Sort Tray SH5000 110 W excluding peak consumption—Cover Interposer CI5040 30 W or less—Decurl Unit DU5070 60 W or less—Multi-Folding Unit FD5030 80 W—Fiery EB-36 controller
Warm-up time
300 seconds or less—at temperature of 23&deg;C
Sound power level
Mainframe 60.4 dB or less—standby 72 dB or less—printing Full system 78.1 dB or less—printing
Emission levels
0.02 mg/h or less—benzene 1.5 mg/h or less—dust 0.48 mg/h or less—ozone 0.10 mg/h or less—styrene
Safety standards
EN62368-1 IEC60950-1
Electromagnetic Compatibility (EMC) standards
EN62311 EN55032 EN55035 EN61000-3-2, EN61000-3-3 AS/NZS CISPR32
Wireless LAN standards
EN301489-1 EN301489-3 EN301489-17 AS/NZS 4268
Typical Electricity Consumption (TEC)
13.6 kWh
Total Volatile Organic Compounds (TVOC)
4.18 mg/h—printing 0.0092 mg/h—standby

Pro 8420

Configuration
Functions
Print
Colour
No
Printer controller - standard
GWNX
Printer controller - optional
Fiery EB-36 controller
Storage
640 GB (320 GB x 2)
Document server
Maximum stored documents 3,000 Maximum pages of all stored documents 15,000 Maximum storage period 1-180 days, 1-96 hours, or no limit
CPU
Intel ApolloLake E3940 1.6 GHz
Memory - standard
2 GB
Operation panel
10.1” Smart Operation Panel (G3)
Physical dimensions
Physical dimensions (WxDxH)—mainframe
1,141 x 900 x 1,750 mm
Physical dimensions (WxDxH)—other
540 x 730 x 1,000 mm—5,000-sheet LCIT RT5160 (A4) 865 x 730 x 1,000 mm—4,400-sheet LCIT RT5170 (A3) 1,054 x 730 x 1,000 mm—4,840-sheet Vacuum-Feed LCIT RT5150 690 x 561 x 210 mm—500-sheet Multi-Bypass Tray BY5020 1,090 x 561 x 210 mm—Multi-Bypass Banner Tray Type S9, when attached to Multi-Bypass Tray BY5020 330 x 730 x 1,000 mm—Bridge Unit BU5010 1,113 x 730 x 1,490 mm—4,500-sheet Finisher SR5110 1,113 x 730 x 1,490 mm—3,500-sheet Booklet Finisher SR5120 1,115 x 591 x 555 mm—Trimmer Unit TR5050 330 x 730 x 1,350 mm—Cover Interposer CI5040 900 x 730 x 1,010 mm—High-Capacity Stacker SK5040 470 x 730 x 1,000 mm—Multi-Folding Unit FD5020 209 x 730 x 1,000 mm—Multi-Folding Unit FD5030 330 x 740 x 1,010 mm—Bridge Unit BU5020 330 x 730 x 1,010 mm—Buffer Pass Unit Type S11 265 x 253 x 136 mm—RPIP Interface Box Type S3
Weight—mainframe
413 kg
Weight—other
106 kg—5,000-sheet LCIT RT5160 (A4) 185 kg—4,400-sheet LCIT RT5170 (A3) 230 kg—4,840-sheet Vacuum-Feed LCIT RT5150 20 kg—500-sheet Multi-Bypass Tray BY5020 3.5 kg—500-sheet Multi-Bypass Banner Tray Type S9 40 kg—Bridge Unit BU5010 135 kg—4,500-sheet Finisher SR5110 160 kg—3,500-sheet Booklet Finisher SR5120 75 kg—Trimmer Unit TR5050 50 kg—Cover Interposer CI5040 131 kg—High-Capacity Stacker SK5040 15 kg—Roll-Away Cart 92 kg—Multi-Folding Unit FD5020 45 kg—Multi-Folding Unit FD5030 40 kg—Bridge Unit BU5020 90 kg—Buffer Pass Unit Type S11
Minimum space requirements
100 mm—left 47 mm—rear 100 mm—right 57 mm—front
Reliability
Max monthly volume
1,000,000 prints
Machine life
60,000,000 prints or 5 years, whichever comes first
Duty cycle
4,000,000 prints per month
Average monthly volume
400,000 prints
Average monthly statement
250,000–600,000 prints—recommended document volume
Supply yields
Supply yields
82,000 prints per toner bottle—two bottles can be installed 2,400,000 images per drum unit 860,000 prints per developer bag 1,200,000 sheets per waste toner bottle—selectable as supply or service part Note: Toner yield is measured with the A4 LEF/6% test chart, and will vary depending on the original document, image sizes and type, and the device operating conditions. 5,000 staples per Type X cartridge for finisher SR5110/5120—normal staple 5,000 staples per Type U cartridge for finisher SR5120—saddle stitch staple 5 cartridges per Type X refill for finisher SR5110/5120—normal staple 2 cartridges per Type T refill for finisher SR5120—saddle stitch staple
Media handling
Standard input capacity (sheets)
3,300 sheets (0.1mm)—2,200-sheet tandem tray + 550-sheet paper tray 2 + 550-sheet paper tray 3 3,000 sheets (0.11mm)—2,000-sheet tandem tray + 500-sheet paper tray 2 + 500-sheet paper tray 3
Maximum input capacity (sheets)
16,700
Maximum output capacity (sheets)
15,000
Paper input configuration - standard
2,200-sheet tandem paper input tray (2 x 1,100 sheets), 2 x 550-sheet paper input trays, duplex unit
Paper input configuration - optional
LCIT RT5160 (A4), LCIT RT5170 (A3), Vacuum-Feed LCIT RT5150, Multi-Bypass Tray BY5020, Multi-Bypass Banner Sheet Tray Type S9, Vacuum-Feed Banner Sheet Tray Type S9, Bridge Unit BU5010, A3/11" x 17" Tray Unit TK5020 (internal)
Paper output configuration - optional
Booklet Finisher SR5120, Finisher SR5110, Punch Unit PU5030, Trimmer Unit TR5050 for Booklet Finisher SR5120, Cover Interposer CI5040, SR5000 Series Output Tray For Banner Sheet Type S6, Decurl Unit DU5070, High-Capacity Stacker SK5040, Multi-Folding Unit FD5020, Multi-Folding Unit FD5030, Bridge Unit BU5020 (for third party finishers)
Paper output configuration - 3rd Party
Plockmatic PBM 350e, Plockmatic Rotate Crease Trim (RCT) e, Plockmatic SBT (Square Back Trimmer), Plockmatic CT XL, Plockmatic HCI3500 High-Capacity Interposer, GBC StreamPunch Plus 220V RICOH, GBC StreamWire
Supported media
Tray 1 Plain, Recycled/Coloured, Pre-Printed, Pre-punched, Bond paper, Card Stock, Back Copied Tray 2 Plain, Recycled/Coloured, Pre-Printed, Pre-punched, Bond paper, Card Stock, Back Copied, OHP, Transparency Tray 3 Plain, Recycled/Coloured, Pre-Printed, Pre-punched, Bond paper, Card Stock, Back Copied, Transparency Bypass tray, Bypass banner sheet tray Plain, Recycled/Coloured, Letterhead, Pre-Printed, Pre-punched, Bond paper, Card Stock, OHP, Tab Stock, Back Copied, Transparency, Envelope Note: Back Copied paper can be fed but quality is not guaranteed. LCIT RT5160 Plain, Recycled/Coloured, Letterhead, Pre-Printed, Pre-punched, Bond paper, Card Stock, OHP, Tab Stock, Back Copied, Transparency, Label Note: Back Copied paper can be fed but quality is not guaranteed. LCIT RT5170 Plain, Recycled/Coloured, Letterhead, Pre-Printed, Pre-punched, Bond paper, Card Stock, OHP, Tab Stock, Back Copied, Transparency, Label, Envelope, Gloss/Matte Note: Back Copied and Label paper can be fed but quality is not guaranteed. Vacuum-Feed LCIT RT5150 Plain, Recycled/Coloured, Letterhead, Pre-Printed, Pre-punched, Bond paper, Card Stock, OHP, Tab Stock, Back Copied, Transparency, Label, Envelope, Gloss/Matte, NCR Note: Back Copied and NCR paper (Weight 0) can be fed but quality is not guaranteed. Pre-punched paper feeding direction must be specified. Pre-punched holes must be set to the trailing side of the paper.
Maximum paper size
330.2 x 700 mm
Media weight (g/m2)
40–350
Limitless paper supply
Supported
Connectivity
Interfaces - standard
Mainframe 10Base-T/100Base-Tx/1000Base-T (Gigabit Ethernet) USB 2.0 Type A—2 ports at rear of device, 2 on operation panel (1 card reader) USB 2.0 Type B—1 port at rear of device SD card slot—1 port at rear of device for card option Fiery EB-36 controller 10Base-T/100Base-Tx/1000Base-T (Gigabit Ethernet) Display Port—2 USB 2.0 Type A—4 ports at rear of device USB 3.2—2 ports at rear of device USB 3.0—3 ports on Fiery Quick Touch panel
Network protocols - standard
GWNX controller TCP/IP (IPv4, IPv6) Fiery EB-36 controller TCP/IP (IPv4, IPv6)
Interfaces - optional
Mainframe IEEE 802.11 a/b/g/n/ac Interface Unit Type M52 Fiery EB-36 controller Not available
Print features
Print speed black and white
136 ppm
Printing technology
40-beam Vertical-Cavity Surface-Emitting Laser (VCSEL)
Fusing
Oil-less belt-fusing method
Print resolution
2,400 x 4,800 dpi—maximum Note: Engine print resolution is 1,200 x 4,800 dpi.
Page description languages (PDLs)
Standard PCL, PostScript 3 and PDF emulation, JPEG, TIFF Optional Genuine Adobe PostScript 3 and PDF, Intelligent Printer Data Stream (IPDS), XPS
Printer driver resolution
PCL 5 300 x 300 dpi, 600 x 600 dpi—1-bit PCL 6 600 x 600 dpi, 1,200 x 1,200 dpi—1-bit PostScript 3 300 x 300 dpi, 600 x 600 dpi, 1,200 x 1,200 dpi—1-bit IPDS 300 x 300 dpi, 600 x 600 dpi—1-bit
Duplex printing
Standard
Envelope printing
Supported—Bypass Tray BY5020, LCIT RT5170, Vacuum-Feed LCIT RT5150
Maximum printable area
Simplex, edge-to-edge print mode 320 x 457.2 mm—mainframe tray 2 320 x 487.7 mm—with A3 LCIT and bypass tray options Note: Image quality in areas that interfere with the print margins is not guaranteed.
Fiery controller
EFI Fiery EB-36 print controller—optional System version Fiery FS600 Pro Configuration External Printer driver languages PostScript 3 (CPSI v3020 and APPE v6.0), PCL 6 Resolution 1,200 dpi, 600 dpi Fonts PCL—80 PostScript 3 — 138 Supported file formats PS, PDF, EPS, TIFF, PPML, PDF/VT, FF1 &FF2 JPEG, DOC, DOCX, XLS, XLSX, PUB, PPT, PPTX Variable data printing (VDP) PPML v3.0 Fiery FreeForm v1 and 2.1 PDF/VT-1 and PDF/VT-2
Other print features
Purge tray, Decurl unit—optional, Media Identification Unit—optional, Limitless toner supply—twin toner bottles, Double feed detection, Sample print, Locked print, Hold print, Scheduled print, Stored print, Store and Print, CLP simulation, PDF Direct print, Mail to print, Classification codes, Bonjour, Windows Active Directory support, DDNS, PCL resident font adoption, Tray parameter change from Web Image Monitor, WS printer, Media Direct Print (Print from USB), Automatic job promotion, Poster print, Job spool
Print margin
Lead edge 4.0 &plusmn; 0.5 mm Trail edge 4.0 &plusmn; 1.0 mm (Print) Front 2.0 &plusmn; 1.5 mm Rear 2.0 &plusmn; 1.5 mm
Supported operating environments
Other supported environments
Fiery system requirements Windows operating systems These Windows versions (with latest service packs) are supported for printer drivers and Fiery applications: Windows 10—64-bit Windows 11—64-bit Windows Server 2016—64-bit Windows Server 2019 Windows Server 2022 Note: Please visit the EFI website to confirm the latest supported OS. Macintosh operating systems These Mac OS versions are supported for printer drivers: Mac OS v10.15.11, 12, 13, 14 Note: Please visit the EFI website to confirm the latest supported OS. HDD—for printing and utilities except Command WorkStation Windows—16 GB of available hard drive space Mac OS X—7 GB of available hard drive space Memory (RAM)—for printing and utilities except Command WorkStation Windows—4 GB of RAM or more recommended Mac OS X—4 GB of RAM or more recommended Networking protocols Windows—TCP/IP Mac OS X—TCP/IP, Bonjour Command WorkStation A monitor that supports 16-bit colour at a minimum resolution of 1,024 x 768 pixels TCP/IP networking protocol installed Windows 1.0 GHz or greater Pentium 4 processor 1 GB RAM or more Mac OS Intel processor that supports the version of Mac OS installed 4 GB RAM or more SeeQuence (Impose and Compose) on Command WorkStation In addition to requirements for Command WorkStation: Licence activation for every client workstation Acrobat/PitStop software
Software and solutions
Standard
Device management and monitoring @Remote Web Image Monitor Device Manager NX Lite Workflow solutions Streamline NX TotalFlow Production Manager TotalFlow Prep RICOH InfoPrint Manager BatchBuilder RICOH Process Director RICOH Supervisor FusionPro VDP Creator
Environmental features
Power source
220–240 V, 50/60 Hz, 16 Amps—mainframe 100–240 V, 50/60 Hz, 1–1.5 Amps—Fiery controller
Power consumption
3,520 W—maximum 0.94 W—Energy Saver Mode (Sleep Mode)
Power consumption—options
224 W—5,000-sheet LCIT RT5160 (A4) 324 W or less—4,400-sheet LCIT RT5170 (A3) 1,000 W—4,840-sheet Vacuum-Feed LCIT RT5150 150 W—4,500-sheet Finisher SR5110 150 W—3,500-sheet Booklet Finisher SR5120 250 W maximum, 75 W average—Trimmer Unit TR5050 95 W excluding peak consumption—Cover Interposer CI5040 30 W or less—Decurl Unit DU5070 144 W—High-Capacity Stacker SK5040 240 W—Multi-Folding Unit FD5020 60 W or less—Multi-Folding Unit FD5030 200 W or less—Buffer Pass Unit Type S11 8 W or less—Bridge Unit BU5020 80 W—Fiery EB-36 controller
Warm-up time
300 seconds or less—at temperature of 23&deg;C
Sound power level
Mainframe 60.4 dB or less—standy 73.7 dB or less—printing Full system 78.8 dB or less—printing
Emission levels
0.02 mg/h or less—benzene 1.5 mg/h or less—dust 0.48 mg/h or less—ozone 0.10 mg/h or less—styrene
Safety standards
EN62368-1 IEC60950-1
Electromagnetic Compatibility (EMC) standards
EN62311 EN55032 EN55035 EN61000-3-2, EN61000-3-3 AS/NZS CISPR32
Wireless LAN standards
EN301489-1 EN301489-3 EN301489-17 AS/NZS 4268
Typical Electricity Consumption (TEC)
17.7 kWh
Total Volatile Organic Compounds (TVOC)
4.18 mg/h—printing 0.0092 mg/h—standby

Pro 8420S

Configuration
Functions
Copy, print, scan
Colour
No
Printer controller - standard
GWNX
Printer controller - optional
Fiery EB-36 controller
Storage
640 GB (320 GB x 2)
Document server
Maximum stored documents 3,000 Maximum pages of all stored documents 15,000 Maximum storage period 1-180 days, 1-96 hours, or no limit
CPU
Intel ApolloLake E3940 1.6 GHz
Memory - standard
2 GB
Operation panel
10.1" Smart Operation Panel (G3)
Physical dimensions
Physical dimensions (WxDxH)—mainframe
1,141 x 900 x 1,750 mm
Physical dimensions (WxDxH)—other
540 x 730 x 1,000 mm—5,000-sheet LCIT RT5160 (A4) 865 x 730 x 1,000 mm—4,400-sheet LCIT RT5170 (A3) 1,054 x 730 x 1,000 mm—4,840-sheet Vacuum-Feed LCIT RT5150 690 x 561 x 210 mm—500-sheet Multi-Bypass Tray BY5020 1,090 x 561 x 210 mm—Multi-Bypass Banner Tray Type S9, when attached to Multi-Bypass Tray BY5020 330 x 730 x 1,000 mm—Bridge Unit BU5010 1,113 x 730 x 1,490 mm—4,500-sheet Finisher SR5110 1,113 x 730 x 1,490 mm—3,500-sheet Booklet Finisher SR5120 1,115 x 591 x 555 mm—Trimmer Unit TR5050 330 x 730 x 1,350 mm—Cover Interposer CI5040 900 x 730 x 1,010 mm—High-Capacity Stacker SK5040 470 x 730 x 1,000 mm—Multi-Folding Unit FD5020 209 x 730 x 1,000 mm—Multi-Folding Unit FD5030 330 x 740 x 1,010 mm—Bridge Unit BU5020 330 x 730 x 1,010 mm—Buffer Pass Unit Type S11 265 x 253 x 136 mm—RPIP Interface Box Type S3
Weight—mainframe
428 kg
Weight—other
106 kg—5,000-sheet LCIT RT5160 (A4) 185 kg—4,400-sheet LCIT RT5170 (A3) 230 kg—4,840-sheet Vacuum-Feed LCIT RT5150 20 kg—500-sheet Multi-Bypass Tray BY5020 3.5 kg—500-sheet Multi-Bypass Banner Tray Type S9 40 kg—Bridge Unit BU5010 135 kg—4,500-sheet Finisher SR5110 160 kg—3,500-sheet Booklet Finisher SR5120 75 kg—Trimmer Unit TR5050 50 kg—Cover Interposer CI5040 131 kg—High-Capacity Stacker SK5040 15 kg—Roll-Away Cart 92 kg—Multi-Folding Unit FD5020 45 kg—Multi-Folding Unit FD5030 40 kg—Bridge Unit BU5020 90 kg—Buffer Pass Unit Type S11
Minimum space requirements
100 mm—left 47 mm—rear 100 mm—right 57 mm—front
Reliability
Max monthly volume
1,000,000 prints
Machine life
60,000,000 prints or 5 years, whichever comes first
Duty cycle
4,000,000 prints per month
Average monthly volume
250,000 prints
Average monthly statement
150,000–500,000 prints—recommended document volume
Supply yields
Supply yields
82,000 prints per toner bottle—two bottles can be installed 2,400,000 images per drum unit 860,000 prints per developer bag 1,200,000 sheets per waste toner bottle—selectable as supply or service part Note: Toner yield is measured with the A4 LEF/6% test chart, and will vary depending on the original document, image sizes and type, and the device operating conditions. 5,000 staples per Type X cartridge for finisher SR5110/5120—normal staple 5,000 staples per Type U cartridge for finisher SR5120—saddle stitch staple 5 cartridges per Type X refill for finisher SR5110/5120—normal staple 2 cartridges per Type T refill for finisher SR5120—saddle stitch staple
Media handling
Standard input capacity (sheets)
3,300 sheets (0.1mm)—2,200-sheet tandem tray + 550-sheet paper tray 2 + 550-sheet paper tray 3 3,000 sheets (0.11mm)—2,000-sheet tandem tray + 500-sheet paper tray 2 + 500-sheet paper tray 3
Maximum input capacity (sheets)
16,700
Maximum output capacity (sheets)
15,000
Paper input configuration - standard
2,200-sheet tandem paper input tray (2 x 1,100 sheets), 2 x 550-sheet paper input trays, 220-sheet SPDF, duplex unit
Paper input configuration - optional
LCIT RT5160 (A4), LCIT RT5170 (A3), Vacuum-Feed LCIT RT5150, Multi-Bypass Tray BY5020, Multi-Bypass Banner Sheet Tray Type S9, Vacuum-Feed Banner Sheet Tray Type S9, Bridge Unit BU5010, A3/11" x 17" Tray Unit TK5020 (internal)
Paper output configuration - optional
Booklet Finisher SR5120, Finisher SR5110, Punch Unit PU5030, Trimmer Unit TR5050 for Booklet Finisher SR5120, Cover Interposer CI5040, SR5000 Series Output Tray For Banner Sheet Type S6, Decurl Unit DU5070, High-Capacity Stacker SK5040, Multi-Folding Unit FD5020, Multi-Folding Unit FD5030, Bridge Unit BU5020 (for third party finishers)
Paper output configuration - 3rd Party
Plockmatic PBM 350e, Plockmatic Rotate Crease Trim (RCT) e, Plockmatic SBT (Square Back Trimmer), Plockmatic CT XL, Plockmatic HCI3500 High-Capacity Interposer,GBC StreamPunch Plus 220V RICOH, GBC StreamWire
Supported media
Tray 1 Plain, Recycled/Coloured, Pre-Printed, Pre-punched, Bond paper, Card Stock, Back Copied Tray 2 Plain, Recycled/Coloured, Pre-Printed, Pre-punched, Bond paper, Card Stock, Back Copied, OHP, Transparency Tray 3 Plain, Recycled/Coloured, Pre-Printed, Pre-punched, Bond paper, Card Stock, Back Copied, Transparency Bypass tray, Bypass banner sheet tray Plain, Recycled/Coloured, Letterhead, Pre-Printed, Pre-punched, Bond paper, Card Stock, OHP, Tab Stock, Back Copied, Transparency, Envelope Note: Back Copied paper can be fed but quality is not guaranteed. LCIT RT5160 Plain, Recycled/Coloured, Letterhead, Pre-Printed, Pre-punched, Bond paper, Card Stock, OHP, Tab Stock, Back Copied, Transparency, Label Note: Back Copied paper can be fed but quality is not guaranteed. LCIT RT5170 Plain, Recycled/Coloured, Letterhead, Pre-Printed, Pre-punched, Bond paper, Card Stock, OHP, Tab Stock, Back Copied, Transparency, Label, Envelope, Gloss/Matte Note: Back Copied and Label paper can be fed but quality is not guaranteed. Vacuum-Feed LCIT RT5150 Plain, Recycled/Coloured, Letterhead, Pre-Printed, Pre-punched, Bond paper, Card Stock, OHP, Tab Stock, Back Copied, Transparency, Label, Envelope, Gloss/Matte, NCR Note: Back Copied and NCR paper (Weight 0) can be fed but quality is not guaranteed. Pre-punched paper feeding direction must be specified. Pre-punched holes must be set to the trailing side of the paper.
Maximum paper size
330.2 x 700 mm
Media weight (g/m2)
40–350
Limitless paper supply
Supported
Connectivity
Interfaces - standard
Mainframe 10Base-T/100Base-Tx/1000Base-T (Gigabit Ethernet) USB 2.0 Type A—2 ports at rear of device, 2 on operation panel (1 card reader) USB 2.0 Type B—1 port at rear of device SD card slot—1 port at rear of device for card option Fiery EB-36 controller 10Base-T/100Base-Tx/1000Base-T (Gigabit Ethernet) Display Port—2 USB 2.0 Type A—4 ports at rear of device USB 3.2—2 ports at rear of device USB 3.0—3 ports on Fiery Quick Touch panel
Network protocols - standard
GWNX controller TCP/IP (IPv4, IPv6) Fiery EB-36 controller TCP/IP (IPv4, IPv6)
Interfaces - optional
Mainframe IEEE 802.11 a/b/g/n/ac Interface Unit Type M52 Fiery EB-36 controller Not available
Copy features
Copy speed
136 cpm
First copy time
4.6 seconds or less
Copy resolution
2,400 x 4,800 dpi—printing 600 x 600 dpi—scanning
Original size
Maximum 297 x 432 mm 297 x 431.8 mm—SPDF
Quantity selection
1–9,999
Zoom range
25%–400%, in 1% steps
Image density adjustment
9 levels
Colour mode
Greyscale—256 levels
Book copy
Supported
Series copy
Book to simplex, duplex to simplex
Combine copy
2, 4, or 8 pages into 1 simplex sheet 1, 2, or 4 duplex pages into 1 simplex sheet 4, 8, or 16 pages into 1 duplex sheet 2, 4, or 8 duplex pages into 1 duplex sheet
Cover sheet
Front and back covers—copy or blank
Slip sheet
Supported
Chaptering
Up to 100 chapters
Stapling
Supported—with finisher
Punch
Supported—with finisher and punch unit
Electronic sorting
Without shift sort—supported Rotate sort—not supported Shift sort—supported—with finisher or shift sort tray
Margin/erase adjustment
Margin adjustment 0–30mm—in 1 mm steps Default—Front page: 5mm left, Back page:5 mm right Erase centre and border 2–99 mm in 1 mm steps Creep Supported (magazine) Scan position Supported
Image adjustment
Sharp/soft—7 levels Contrast—9 levels Background density adjustment—9 levels
Stamps
User stamp—5 stamps Date stamp—4 styles Page numbering—6 styles Preset stamp—8 stamps Bates stamping—6 styles Printing copy prevention pattern—supported
Job presets
Up to 10 presets
Job programs
Up to 50 jobs
Copy modes
Text, Photo, Text/Photo, Generation Copy, Pale
Auto tray change
Supported
Centring
Supported
Image creation
Repeated, Double copy, Positive/negative, Erase inside, Erase outside
Other copy features
Home UI customisation, My Operation Panel, Operation manual on operation panel, External USB keyboard, QWERTZ layout keyboard, AZERTY layout keyboard, Smart device-like operability, Tiltable operation panel, Interrupt copy, Import/Export of user preference settings, Centralised address book management, Job log data report printout, Subset stapling, Text and photo separation sensitivity adjustment—9 levels, Sample copy
Print features
Print speed black and white
136 ppm
Printing technology
40-beam Vertical-Cavity Surface-Emitting Laser (VCSEL)
Fusing
Oil-less belt-fusing method
Print resolution
2,400 x 4,800 dpi—maximum Note: Engine print resolution is 1,200 x 4,800 dpi.
Page description languages (PDLs)
Standard PCL, PostScript 3 and PDF emulation, JPEG, TIFF Optional Genuine Adobe PostScript 3 and PDF, Intelligent Printer Data Stream (IPDS), XPS
Printer driver resolution
PCL 5 300 x 300 dpi, 600 x 600 dpi—1-bit PCL 6 600 x 600 dpi, 1,200 x 1,200 dpi—1-bit PostScript 3 300 x 300 dpi, 600 x 600 dpi, 1,200 x 1,200 dpi—1-bit IPDS 300 x 300 dpi, 600 x 600 dpi—1-bit
Duplex printing
Standard
Envelope printing
Supported—Bypass Tray BY5020, LCIT RT5170, Vacuum-Feed LCIT RT5150
Maximum printable area
Simplex, edge-to-edge print mode 320 x 457.2 mm—mainframe tray 2 320 x 487.7 mm—with A3 LCIT and bypass tray options Note: Image quality in areas that interfere with the print margins is not guaranteed.
Fiery controller
EFI Fiery EB-36 print controller—optional System version Fiery FS600 Pro Configuration External Printer driver languages PostScript 3 (CPSI v3020 and APPE v6.0), PCL 6 Resolution 1,200 dpi, 600 dpi Fonts PCL—80 PostScript 3 — 138 Supported file formats PS, PDF, EPS, TIFF, PPML, PDF/VT, FF1 &FF2 JPEG, DOC, DOCX, XLS, XLSX, PUB, PPT, PPTX Variable data printing (VDP) PPML v3.0 Fiery FreeForm v1 and 2.1 PDF/VT-1 and PDF/VT-2
Other print features
Purge tray, Decurl unit—optional, Media Identification Unit—optional, Limitless toner supply—twin toner bottles, Double feed detection—mainframe (standard); document feeder (optional), Sample print, Locked print, Hold print, Scheduled print, Stored print, Store and Print, CLP simulation, PDF Direct print, Mail to print, Classification codes, Bonjour, Windows Active Directory support, DDNS, PCL resident font adoption, Tray parameter change from Web Image Monitor, WS printer, Media Direct Print (Print from USB), Automatic job promotion, Poster print, Job spool
Print margin
Lead edge 4.0 &plusmn; 0.5 mm Trail edge 4.0 &plusmn; 1.0 mm (Print) Front 2.0 &plusmn; 1.5 mm Rear 2.0 &plusmn; 1.5 mm
Scan features
Scan speed
140 ipm—simplex 280 ipm—duplex
Scan methods
Scan to USB/SD, Scan to email, Scan to folder (SMB, FTP) Scan to URL, Scan to PDF/A, Scan to digitally signed PDF, Scan to searchable PDF (embedded) Note: Maximum scan size for 1,200 dpi is A5.
Scan mode
Black and white Text, text/line art, text/photo, photo, greyscale Colour Text/photo, glossy photo, Automatic Colour Selection
Scan area
Main scan 297 mm Sub-scan 432 mm 431.8 mm—from SPDF
Image density adjustment
Supported—9 levels
Scan to email—other features
Scan to email size 128–102,400 KB—with restriction 700 MB—without restriction Maximum email addresses per send 2,000—from HDD 500—direct input 100—via LDAP Email addresses stored in HDD Maximum email addresses—2,000 Maximum registered group addresses—500 Search method—by name, email address Body message Manual—maximum 80 characters over 1 line User pre-registered—maximum 400 characters via soft key, 80 characters over 5 lines Preset message—This e-mail includes attached file sent from <device name> Input subject Manual and user pre-registered—maximum 128 characters via soft key Preset message—supported LDAP search Supported Input file name Supported Input of destination email address via soft key Supported Simultaneous transmission Maximum 500 destinations Attention To, Cc, Bcc Program registration Up to 25 programs Divide and send Divide by page or size; default divide by size Resend Yes—default/No, retry 3 times
Scan to folder
Protocols SMB, FTP Resolution 100 dpi, 150 dpi, 200 dpi (default), 300 dpi, 400 dpi, 600 dpi Search for client folders SMB—browsing directly to the designated folder Scan to folder file types Single-page TIFF, JPEG, PDF, PDF/A, high-compression PDF Multi-page TIFF, PDF, PDF/A, high-compression PDF
Scanner compression methods
Black and white JBIG2, MH, MMR, MR Colour JPEG
Scanned file naming
Supported—with reference number setting, for example, SCAN0001
Scan to file types
Single- and multi-page TIFF Single-page JPEG Single- and multi-page PDF Single-page high-compression PDF
Other scan features
SADF/batch mode, Mixed size mode, Reduce/enlarge scanning, Split scan from booklet, WS scanner, LDAP support (email), Preview before transmission, PDF encryption, Drop-out colour send, Distributed Scan Management
Supported operating environments
Other supported environments
Fiery system requirements Windows operating systems These Windows versions (with latest service packs) are supported for printer drivers and Fiery applications: Windows 10—64-bit Windows 11—64-bit Windows Server 2016—64-bit Windows Server 2019 Windows Server 2022 Note: Please visit the EFI website to confirm the latest supported OS. Macintosh operating systems These Mac OS versions are supported for printer drivers: Mac OS v10.15.11, 12, 13, 14 Note: Please visit the EFI website to confirm the latest supported OS. HDD—for printing and utilities except Command WorkStation Windows—16 GB of available hard drive space Mac OS X—7 GB of available hard drive space Memory (RAM)—for printing and utilities except Command WorkStation Windows—4 GB of RAM or more recommended Mac OS X—4 GB of RAM or more recommended Networking protocols Windows—TCP/IP Mac OS X—TCP/IP, Bonjour Command WorkStation A monitor that supports 16-bit colour at a minimum resolution of 1,024 x 768 pixels TCP/IP networking protocol installed Windows 1.0 GHz or greater Pentium 4 processor 1 GB RAM or more Mac OS Intel processor that supports the version of Mac OS installed 4 GB RAM or more SeeQuence (Impose and Compose) on Command WorkStation In addition to requirements for Command WorkStation: Licence activation for every client workstation Acrobat/PitStop software
Software and solutions
Standard
Device management and monitoring @Remote Web Image Monitor Device Manager NX Lite Workflow solutions Streamline NX TotalFlow Production Manager TotalFlow Prep RICOH InfoPrint Manager BatchBuilder RICOH Process Director RICOH Supervisor FusionPro VDP Creator
Environmental features
Power source
220–240 V, 50/60 Hz, 16 Amps—mainframe 100–240 V, 50/60 Hz, 1–1.5 Amps—Fiery controller
Power consumption
3,520 W—maximum 0.94 W—Energy Saver Mode (Sleep Mode)
Power consumption—options
224 W—5,000-sheet LCIT RT5160 (A4) 324 W or less—4,400-sheet LCIT RT5170 (A3) 1,000 W—4,840-sheet Vacuum-Feed LCIT RT5150 67 W—3,250-sheet Finisher SR5130 67 W—3,250-sheet Booklet Finisher SR5140 15 W—Output Jogger Unit Type S11 150 W—1,000-sheet Finisher SR5110 150 W—1,000-sheet Booklet Finisher SR5120 250 W maximum, 75 W average—Trimmer Unit TR5050 20 W—Shift Sort Tray SH5000 110 W excluding peak consumption—Cover Interposer CI5040 30 W or less—Decurl Unit DU5070 60 W or less—Multi-Folding Unit FD5030 80 W—Fiery EB-36 controller
Warm-up time
300 seconds or less—at temperature of 23&deg;C
Sound power level
Mainframe 60.4 dB or less—standby 73.7 dB or less—printing Full system 78.8 dB or less—printing
Emission levels
0.02 mg/h or less—benzene 1.5 mg/h or less—dust 0.48 mg/h or less—ozone 0.10 mg/h or less—styrene
Safety standards
EN62368-1 IEC60950-1
Electromagnetic Compatibility (EMC) standards
EN62311 EN55032 EN55035 EN61000-3-2, EN61000-3-3 AS/NZS CISPR32
Wireless LAN standards
EN301489-1 EN301489-3 EN301489-17 AS/NZS 4268
Typical Electricity Consumption (TEC)
17.2 kWh
Total Volatile Organic Compounds (TVOC)
4.18 mg/h—printing 0.0092 mg/h—standby

let’s talk print

your next chapter
starts with a conversation.

Tell us what you print, your volumes and where you want to go. We’ll help you explore the next step.

1300 189 476
